Audit against your brokerage

Goal: catch drift between what zfin thinks you hold and what your brokerage actually reports -- wrong share counts, sales you forgot to record, missing lots, stale manual prices -- by reconciling portfolio.srf against a positions export.

You'll need: a portfolio whose accounts.srf entries carry institution:: and account_number:: (that's how zfin ties an export back to your accounts -- see How accounts are matched), plus an export from a supported broker.

Heads up: this is the most heuristic corner of zfin. The brokerage parsers are format-specific, account matching depends on metadata you maintain, and the comparison uses deliberate tolerances. It's the best way to keep your records honest, but expect a little setup and the occasional "why didn't that match?" -- this guide covers the gotchas, not just the happy path.

Supported brokers and how to export

zfin audit reconciles against Fidelity and Schwab. (Wells Fargo is handled by import, not audit.)

Broker	How to export	Flag
Fidelity	Positions tab -> the three-dot (⋮) menu -> Download (a CSV)	`--fidelity <CSV>`
Schwab (per-account)	Accounts -> Positions -> Export (one CSV per account)	`--schwab <CSV>`
Schwab (summary)	Accounts -> Summary: select the accounts table and copy it (what to copy)	`--schwab-summary`

The two Schwab inputs differ in detail: the per-account CSV has full per-position data (shares, price, value); the summary paste carries only each account's cash and total value, so it reconciles totals, not individual holdings. Use the summary for a quick "are my account totals right?", the CSV for position-level checks. (Fidelity money-market rows and Schwab "Cash & Cash Investments" rows are recognized as cash.)

The Fidelity Download isn't a top-level button -- it's behind the three-dot (⋮) menu at the top-right of the positions panel:

(The account list down the left side is blanked out above.)

Schwab summary: what to copy

The summary paste comes from Schwab's Accounts -> Summary page. Scroll to the Accounts table, drag-select from the first account's name through the last row, and copy. Then either save it as a .txt file in your audit/ folder (where auto-discovery will find it) or pipe it straight in:

zfin audit --schwab-summary    # paste, then Ctrl-D

A good paste is repeating three-line blocks -- the account name, the "ending in" line, then a values line -- and looks about like this (figures fictional):

Sample Roth IRA
Account number ending in 1234 ...1234
Type IRA $46.44 $227,058.15 +$1,072.88 +0.47%
Sample Brokerage
Account number ending in 5678 ...5678
Type Brokerage $12,500.00 $980,000.00 +$3,200.00 +0.33%
Sample Trust
Account number ending in 9012 ...9012
Type $2,000.00 $415,300.00 +$1,150.00 +0.28%

zfin anchors on each "Account number ending in" line (its trailing digits are the account number) and reads the first two dollar figures on the line below as cash then total value -- everything else on that line is ignored, and the account-type word is optional. If your copy looks nothing like this -- no "ending in" lines, or no dollar figures -- you grabbed the wrong region. Because it carries only cash and totals, the summary reconciles account totals, not individual positions.

Run it

Point it at a file:

ZFIN_HOME=~/finance zfin audit --fidelity ~/Downloads/Portfolio_Positions.csv
ZFIN_HOME=~/finance zfin audit --schwab   ~/Downloads/Positions-Individual.csv
ZFIN_HOME=~/finance zfin audit --schwab-summary    # then paste the page, Ctrl-D

Or run it with no flags -- zfin audit does a portfolio hygiene check and auto-discovers and reconciles any recent exports it finds (next two sections).

The hygiene check

With no flags, zfin audit first prints a health report:

Stale manual prices -- lots with a manual price:: older than --stale-days (default 3).
Accounts overdue for update -- accounts past their update_cadence (see accounts.srf).
Brokerage files it discovered, which it then reconciles.
Config file problems -- field-name typos in your .srf files, impossible lot dates, and values zfin had to ignore or adjust.

  Portfolio hygiene

  Stale manual prices (>3 days - --stale-days to configure)
    (none)

  Accounts overdue for update (weekly default - set update_cadence in accounts.srf)
    Sample IRA                       weekly    no update history found
    Sample Brokerage                 weekly    no update history found

"No update history found" is a nudge, not an error -- silence accounts you don't actively track with update_cadence::none.

Config file problems

Your .srf files can be wrong in ways that don't stop them loading. zfin reads what it understands and quietly ignores or works around the rest, so a mistake can change your numbers with no error at all. zfin audit checks portfolio*.srf, accounts.srf, metadata.srf, transaction_log.srf, projections.srf, and watchlist.srf for three kinds of problem, and prints nothing when there aren't any:

  Config file problems
    portfolio.srf
      line 3: unrecognized field 'price_dat' - did you mean 'price_date'?
      line 4: BND close_date 2062-03-14 is in the future - the lot is still counted as held until then
      line 5: AAPL has close_date but no close_price - the sale's realized gain is recorded as 0
      valid fields:
        symbol shares open_date open_price close_date close_price note
          label account security_type maturity_date rate drip ticker price
          price_date price_ratio split_factor underlying strike multiplier
          option_type
    accounts.srf
      line 2: account 'Sample Brokerage': audit_large_lot_threshold must be > 0 (got 0); ignored, so the audit uses its default
      line 4: account 'Sample Roth': tax_mix_* must not name the account's own tax_type; the tax mix is ignored and the account counts wholly as roth

Each finding names the line of the record it came from, and the date and value findings also say what zfin is doing instead of what you wrote.

1. Field names (every file)

SRF matches record keys against field names exactly. A key that matches nothing is discarded without complaint -- a misspelled price_dat:: is indistinguishable from having left the price date out. Most fields have defaults, so most typos change behavior with no output at all.

Report	Meaning
`did you mean '...'?`	A dropped or doubled character. The suggested name is a real field.
`differs only by case`	`Account` is not `account`. Matching is case-sensitive, so this silently does nothing.
`ignored for security_type`	A real field that this kind of lot never reads -- e.g. `rate` outside a `cd`.
`appears twice`	SRF keeps the first occurrence. Editing the second one has no effect.
`derived by zfin`	zfin computes this field; a hand-written value is overwritten. Delete it.
`unrecognized field`	No match and no close relative. Check it against the `valid fields` list.

The suggestions are deliberately cautious -- they only fire when a real field name is a prefix of what you typed, or differs from it only by case -- so a suggestion is never a guess. That means a typo in the middle of a name (update_cadance) gets no suggestion, which is why the valid fields list is printed whenever a field name is in question. It comes straight from the code, so unlike any document it cannot be out of date.

2. Lot dates (`portfolio*.srf`)

These fields parse fine but describe a lot that can't exist. They matter more than they look: most of zfin decides whether a lot is held by comparing close_date to today, but zfin contributions treats a lot as sold the moment it has any close_date at all -- so a bad date makes the two disagree.

Report	What zfin does with it
`close_date ... is in the future`	Counts the lot as held until that date. Usually a mistyped year.
`close_date ... is before open_date`	The lot is never counted as held on any date.
`has close_date but no close_price`	Stock lots only. The sale's realized gain is recorded as 0.
`has close_price but no close_date`	The lot stays held. On a stock lot, its row shows the close price instead of the live one.
`open_date ... is in the future`	The lot is left out of your positions until that date.
`price_date ... is in the future`	Stock lots only. The manual price counts as fresh, so it is never flagged as stale.

A close dated today is already closed, and a same-day buy-and-sell (close_date equal to open_date) is fine. A future maturity_date is normal -- that is the field for a CD or option that ends on a known date. Watch lots are exempt, since zfin reads only their symbol. See Closed lots.

3. Values zfin rejects or adjusts (`accounts.srf`, `projections.srf`)

Values that parse but can't be used as written. zfin replaces or clamps them so the file still loads -- just not the way you wrote it. Each of these is also logged to stderr when the file loads; the audit is where it gets a line number and can't scroll past.

accounts.srf

Report	What zfin does instead
`audit_large_lot_threshold must be > 0`	Uses the audit's built-in threshold.
`harvested must be a finite number`	Drops the harvested figure (only reachable by typing `inf` or `nan`).
`tax_mix_* ...` (any of the four rules below)	Ignores the whole tax mix; the account counts wholly as its `tax_type`.

The four tax-mix rules: every tax_mix_* carve-out must be above 0 and a finite number, none may name the account's own tax_type, and together they must sum to less than 100. See accounts.srf.

projections.srf

Report	What zfin does instead
`return_cap`, `annual_contribution`, `target_spending`, or `survivor_spending_pct` `must be >= 0`	Ignores that value; an earlier line's value, or the default, stands.
`horizon`, `horizon_age`, or `max_accumulation_years` `must be > 0`	Ignores that value.
`spending_change capped`	Clamps it to 10%/yr either way -- a larger figure is almost always a units slip.
`max_accumulation_years capped`	Clamps it to 100.
`benchmark_stock` / `benchmark_bond` `must be 1..16 chars`	Ignores the symbol and keeps `SPY` / `AGG`.
`retirement_target must be 90, 95, or 99`	Ignores the annotation on that horizon.
`retirement_target set on multiple horizons`	Ignores all of them and uses the default promotion rule. Names both lines.
`horizon limit` / `horizon_age limit` (more than 8 of either)	Ignores the extras.
`event limit` (more than 16), or an event with `start_age 0`	Ignores that event.
`birthdate person index ... exceeds limit` (more than 4 people)	Ignores that birthdate.
`skipping malformed record`	Drops the whole line -- e.g. a misspelled `type::`, or text where a number belongs.
`stopped reading`	Ignores that line and everything after it.

The last two matter most: this file never fails to load, so a line zfin couldn't read otherwise just quietly reverts to defaults. See projections.srf.

Also in `zfin doctor`

zfin doctor reports the same findings one file at a time, with a link to each file's reference page, and also covers keys.srf, theme.srf, and acknowledgments.srf. Neither command changes its exit code over any of these -- they're nudges, not failures.

Auto-discovery (and your download folder)

With no --fidelity/--schwab flag, zfin looks for exports in two places:

$ZFIN_AUDIT_FILES -- a directory you set. Point it at wherever your browser saves downloads (e.g. ~/Downloads) so a just-downloaded export is found with no copying or renaming. (zfin does not scan it on its own -- you opt in by setting this.)
<portfolio-dir>/audit/ -- a dedicated subfolder next to your portfolio.srf, for exports you want to keep around.

What it considers:

Only files modified in the last 24 hours. Your browser saves the export to its download folder with names like Portfolio_Positions_Jun-19.csv; the recency window keeps zfin reconciling the one you just pulled, not last quarter's.
Detected by content, not filename. zfin sniffs the first lines -- Fidelity begins Account Number/Account Name, a Schwab CSV begins "Positions for ..., a Schwab summary contains Account number ending in. A renamed file still works; an unrelated CSV is skipped.

So with ZFIN_AUDIT_FILES=~/Downloads, the workflow collapses to "download from your broker, run zfin audit, done."

How accounts are matched

This is the part that trips people up. An export covers one or more accounts, and zfin has to tie each one to an account in your portfolio. It does that through accounts.srf:

The export carries an account number -- Schwab's from the "Positions for account ...1234" title, Fidelity's from the Account Number column, the summary's from "...ending in 1234".
zfin finds the accounts.srf entry whose institution:: (fidelity, schwab) and account_number:: match, and compares against that account's lots.
No match -> the account is shown as unmapped and flagged as a discrepancy. Fix it by adding institution:: and account_number:: to that account in accounts.srf (a placeholder number you recognize is fine -- it just has to match what the export shows).

Reading the report

zfin treats the brokerage as the source of truth and shows, per account, your portfolio (PF) against the broker (BR). Figures below are illustrative and fictional:

Portfolio Audit  (brokerage is source of truth)
========================================

  Sample Brokerage *1234
    Symbol      PF Shares   BR Shares   PF Price   BR Price
    VTI           100.000     100.000     373.38     373.38   ok
    SCHD          200.000     210.000      31.86      31.86   brokerage +10.000
    AGG            50.000       0.000                          portfolio only

Portfolio-only rows are lots the broker no longer shows -- a sale you forgot to remove, or a mistyped symbol.
Brokerage-only rows are holdings missing from your portfolio.
A share or value delta flags a count or price mismatch.

--verbose prints the full comparison even when everything reconciles.

Discrepancies, and which ones are muted

Cash matches to the penny. It's an exact figure on both sides, so any gap is real (e.g. money-market dividend accrual between updates) and is surfaced as a warning.
Securities get ~$1 of slack for sub-cent NAV rounding on large positions. Beyond that, a value delta is a warning by default -- your records should reconcile to the dollar.
Two cases are muted instead -- still shown (and still in the totals), just greyed out as "expected, you probably don't care." Muting never hides a discrepancy:
- CDs. zfin carries a CD at face value while the broker marks it to the secondary market. That gap is muted up to a band computed from the CD's own rate and time to maturity (capped at one year's coupon); anything larger still warns. We can't reproduce the broker's exact mark without a live yield, so we bound it instead.
- Options. zfin tracks options at cost while the broker marks to market, and that gap is unbounded without a live quote. So an account holding open options mutes its account-level value delta -- drill into the per-position export (--schwab / --fidelity) to check share counts, which are never muted.
Share-count mismatches are never muted.

If a lot is priced through a retail-ticker ticker:: alias while the account actually holds an institutional class (a different NAV), audit compares against the broker's NAV and can suggest a price_ratio to bridge the gap. Accounts flagged direct_indexing::true get the same treatment to track drift. See price resolution.

Why it's finicky

The parsers are broker-specific and hardcode each export's column layout -- if Fidelity or Schwab changes their format, parsing can break (Fidelity's header is validated to catch this; Schwab's is not). They are not full RFC-4180 CSV parsers (no escaped quotes or multi-line fields) -- fine for the real exports, not for arbitrary CSVs.
Matching is only as good as the institution:: / account_number:: entries you keep in accounts.srf.
Options, CDs, and cash are reconciled separately from share counts.

None of this is a reason to skip it -- it's the single best way to keep your records honest -- just know it expects some setup and an occasional manual nudge.

What about Wells Fargo?

Wells Fargo's portal has no clean positions export, so it isn't an audit target. Instead, zfin import --wells-fargo rebuilds a portfolio file from a paste of the WF positions table (copy the rendered table from the brokerage portal and save it to a file). Fidelity and Schwab exports can be imported the same way.

Keep brokerage exports private. They contain real account numbers and holdings. Store them outside any git repository and delete them when you're done reconciling.

Next steps

zfin audit reference -- every flag.
Map your accounts -- the institution / account_number matching keys.
zfin import -- build a portfolio file from an export (including Wells Fargo).
